Emissivity Measurement Apparatus
Product Details:
- Product Type Measurement Apparatus
- Length 170 Millimeter (mm)
- Color Blue and White
- Dimension (L*W*H) 1500 x 1000 x 80 mm Millimeter (mm)
- Voltage 220-440 Volt (v)
- Material Metal
- Warranty 1 Year
- Click to View more
Emissivity Measurement Apparatus Price And Quantity
- 1 Unit
- 100000.00 - 800000.00 INR/Unit
- 1000-800000 INR/Unit
Emissivity Measurement Apparatus Product Specifications
- Metal
- 1500 x 1000 x 80 mm Millimeter (mm)
- Measurement Apparatus
- 1 Year
- 170 Millimeter (mm)
- 220-440 Volt (v)
- Blue and White
Emissivity Measurement Apparatus Trade Information
- 10 Unit Per Day
- 15-30 Days
- All India
Product Description
Emissivity Measurement Apparatus:
The apparatus consists of a test plate and a comparator. A black plate is used as a comparator for test plate. When all the physical, dimensions and the temperatures are equal, heat losses from both plates will also be the same, except radiation losses. Hence the input difference will be due to difference in emissive. Both the plates are kept in a panel enclose with perplex front and are given inputs through separate dimmer stats so that temperatures of both can be kept equal. Thus emissivity can determine over a wide range of temperatures.
Specifications
Test plate and Black plates- 160mm. Dia. Aluminum plates, mounted in Panel with mica heater inside.
Instrumental panel consisting of-
- Voltmeter and ammeter for input measurement to both heaters through a selector switch.
- Separate dimmers for both the plates.
- Multichannel digital temperature indicator.
A technical manual accompanies the unit.
Services required:
- Space area of 1.5m x 1 m. at working height.
- 230v, 15A, AC supply with earthing connection
